Hastelloy C276 Flanges, ASTM B564 Hastelloy C276 Flange

Name: Omaa Forged - Industrial Flanges and Round Bars
Rating: 5

UNS N10276 slip on Flanges Supplier, ANSI B16.5 C276 Threaded Flanges, 2.4819 Socket Weld Flanges, ASTM B564 Hastelloy C276 Pipe Flanges, Hastelloy C276 weld neck Flange, Nickel Alloy C276 Forged Flanges Manufacturer in India.

Hastelloy C276 is a nickel-molybdenum-chromium alloy with exceptional corrosion resistance in a wide range of aggressive environments. Hastelloy C276 flanges are flanges made from this specific alloy.

Hastelloy C276 offers excellent resistance to corrosion from both oxidizing and reducing media, including acids, chlorides, and seawater. It is widely used in industries such as chemical processing, petrochemicals, power generation, and pollution control.

Flanges made from Hastelloy C276 are available in various types, including weld neck, slip-on, threaded, socket weld, and blind flanges. These flanges are designed to connect pipes, valves, and other equipment in a piping system, ensuring a secure and leak-proof joint, even in highly corrosive environments.

When selecting Hastelloy C276 flanges, it is important to consider factors such as pressure rating, size, and connection type to ensure compatibility with the rest of the piping system. It is recommended to consult with a supplier or a qualified engineer to determine the specific requirements for your application and to ensure the proper selection and installation of these flanges.

ANSI/ASME B16.5 ASTM B564 Hastelloy C276 Flanges Supplier

Specifications Material Grades Dimensions Weight Chart Pressure Chart Schedule Chart Size Chart Applications

Hastelloy® Alloy C276 Spectacle Blind Flanges, ISO Approved Alloy C276 Blind Flanges, Check Sizes And Dimensions Of ASTM B564 Forged Flanges, Ready Stock of NiMo16Cr15W Hastelloy Socket Weld Flange, Suppliers of C276 Hastelloy Alloy C276 Welding Neck Flange, Lap joint Flanges.

Hastelloy C276 Flange Specifications

Size Range

1/2" (15 NB) to 48" (1200NB) DN10~DN5000

Class / Pressure Rating

150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Standards / Dimensions

ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605

Connection Type

Ring Joint Flange (RTJ), Flat Face Flange (FF), Raised Face Flange (RF), Male and Female Flange (M & F), Lap Joint Flange, Large and Small Tongue-and-Groove Flange (T & G)

Material Standards

ASTM B564/ ASME SB564

ASTM B564 Hastelloy C276 Flanges Equivalent Grade

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C276	2.4819	N10276	NW 0276	??65???	NiMo16Cr15W	??760

ANSI B16.5 Hastelloy C276 Flanges Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C276	0.010 max	1.00 max	0.08 max	0.03 max	2.50 max	50.99 min*	14.50 ? 16.50	4.00 ? 7.00	15.00 ? 17.00	0.04 max

ASTM B564 Hastelloy C276 Flanges Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C276	8.89 g/cm3	1370 ?C (2500 ?F)	Psi ? 1,15,000 , MPa ? 790	Psi ? 52,000 , MPa ? 355	40 %

Find the largest ready stock of Hastelloy C276 Flanges, C276 Hastelloy Flange Price List, Competitive Price of Hastelloy Alloy C276 Slip on Flange, UNS N10276 Flanges Exporter, Check Availability of ASTM B564 Hastelloy C276 Threaded Flanges, Alloy C276 Reducing Flanges Stockist, ASME SB564 Alloy C276 Plate flange Dimension, Hastelloy Alloy C276 BLRF Flanges Supplier, Hastelloy Alloy C276 Forged Flanges in Mumbai, India.

ASTM B564 Hastelloy C276 Flanges Dimensions & Size

NPS (in.)	Hastelloy C276 Flanges Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

ASTM B564 Hastelloy C276 Flanges Weight Chart

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
15mm (1/2″) Hastelloy C276 Flange Weight Chart
ANSI B16.5 Flanges	ANSI 150 Flanges	89	60	4	13	16
	ANSI 300 Flanges	95	67	4	13	16
	ANSI 600 Flanges	95	67	4	13	16
	ANSI 900 Flanges	121	83	4	19	22
	ANSI 1500 Flanges	121	83	4	19	22
AS4087 Flanges	PN14 Flanges	95	67	4	M12	14
AS 2129 Flange	Table C Flanges	95	67	4	13	14
	Table D Flanges	95	67	4	13	14
	Table E Flanges	95	67	4	13	14
	Table F Flanges	95	67	4	13	14
	Table H Flanges	114	83	4	16	17
	Table J Flanges	114	83	4	16	17
ISO 7005 (DIN) Flange	PN6 Flanges	80	55	4	M10	11
	PN10 Flanges	95	65	4	M12	14
	PN16 Flanges	95	65	4	M12	14
	PN20 Flanges	90	60.5	4	M14	16
	PN25 Flanges	95	65	4	M12	14
	PN40 Flanges	95	65	4	M12	14

Hastelloy C276 Flange Pressure Ratings

NPS (Nominal Pipe Size)	SORF (Slip On)	NPT (Threaded)	SWRF (Socket Weld)	Loose (Lap Joint)	BLRF (Blind)	WRNR (Weld Neck)
½	1	1	2	1	2	2
¾	2	2	2	2	2	2
1	2	2	2	2	2	3
1¼	3	3	3	3	3	3
1½	3	3	3	3	4	4
2	5	5	5	5	5	6
2½	8	8	8	8	7	10
3	9	9	9	9	9	11.5
3½	11	12	11	11	13	12
4	13	13	13	13	17	16.5
5	15	15	15	15	20	21
6	19	19	19	19	27	26
8	30	30	30	30	47	42
10	43	43	43	43	70	54
12	64	64	64	64	123	88
14	90	90	90	105	140	114
16	106	98	98	140	180	140
18	130	130	130	160	220	165
20	165	165	165	195	285	197
22	185	185	185	245	355	225
24	220	220	220	275	430	268

Hastelloy C276 Flanges Dimensional Size Chart

Normal Sizes In inch	Dimension	Hastelloy C276 Flanges Dimensional Sizes 1/2 inch. to 2 1/2 inch.
		Class 125 Class 150		Class 300		Class 400		Class 600		Class 900		Class 1500		Class 2500
		inch.	mm	inch.	millimeter	inch.	mm	inch.	mm	inch.	mm	inch.	mm	inch		mm
1/2	A	3 1/2	88.9	3 3/4	95.2	3 3/4	95.2	3 3/4	95.2	4 3/4	121	4 3/4	121	5 1/4	133.4
	b	7/16	11.1	9/16	14.3	9/16	14.3	9/16	14.3	7/8	22.2	7/8	22.2	1 3/16	30.2
	D2	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9
	D1	2 3/8	60.3	2 5/8	66.7	2 5/8	66.7	2 5/8	66.7	3 1/4	82.6	3 1/4	82.6	3 1/2	88.9
	n	4	4	4	4	4	4	4	4	4	4	4	–	4	44
	d	5/8	15.9	5/8	15.9	5/8	15.9	5/8	15.9	7/8	22.2	7/8	22.2	7/8	22.2
3/4	A	3 7/8	98.4	4 5/8	117.5	4 5/8	117.5	4 5/8	117.5	5 1/8	130	5 1/8	130	5 1/2	139.7
	b	1/2	12.7	5/8	15.9	5/8	15.9	5/8	15.9	1	25.4	1	25.4	1 1/4	31.8
	D2	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9
	D1	2 3/4	69.8	3 1/4	82.5	3 1/4	82.5	3 1/4	82.5	3 1/2	88.9	3 1/2	88.9	3 3/4	95.2
	n	4	4	4	4	4	4	4	4	4	4	4	–	4	44
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	7/8	22.2	7/8	22.2	7/8	22.2
1	A	4 1/4	108	4 7/8	123.8	4 7/8	123.8	4 7/8	123.8	5 7/8	149.2	5 7/8	149.2	6 1/4	159
	b	9/16	14.3	11/16	17.5	11/16	17.5	11/16	17.5	1 1/8	28.6	1 1/8	28.6	1 3/8	34.9
	D2	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8
	D1	3 1/8	79.4	3 1/2	88.9	3 1/2	88.9	3 1/2	88.9	4	102	4	102	4 1/4	108
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1	25.4
1 1/4	A	4 5/8	117.5	5 1/4	133.4	5 1/4	133.4	5 1/4	133.4	6 1/4	159	6 1/4	159	7 1/4	184.2
	b	5/8	15.9	3/4	19	13/16	20.6	13/16	20.6	1 1/8	28.6	1 1/8	28.6	1 1/2	38.1
	D2	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5
	D1	3 1/2	88.9	3 7/8	98.4	3 7/8	98.4	3 7/8	98.4	4 3/8	111	4 3/8	111	5 1/8	130
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1 1/8	28.6
1 1/2	A	5	127	6 1/8	155.6	6 1/8	155.6	6 1/8	155.6	7	177.8	7	177.8	8	203
	b	11/16	17.5	13/16	20.6	7/8	22.2	7/8	22.2	1 1/4	31.8	1 1/4	31.8	1 3/4	44.5
	D2	2 7/8	73 98	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73
	D1	3 7/8	4	4 1/2	114	4 1/2	114	4 1/2	114	4 7/8	124	4 7/8	124	5 3/4	146
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	. 15.9	7/8	22.2	7/8	22.2	7/8	22.2	1 1/8	28.6	1 1/8	28.6	1 1/4	31.8
2	A	6	152.4	6 1/2	165.1	6 1/2	165.1	6 1/2	165.1	8 1/2	215.9	8 1/2	215.9	9 1/4	234.9
	b	3/4	19	7/8	22.2	1	25.4	1	25.4	1 1/2	38.1	1 1/2	38.1	2	50.8
	D2	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1
	D1	4 3/4	121	5	127	5	127	5	127	6 1/2	165.1	6 1/2	165.1	6 3/4	171
	n	4	4	8	8	8	8	8	8	8	8	8	8	8	8
	d	3/4	19	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1 1/8	28.6
2 1/2	A	7	177.8	7 1/2	190.5	7 1/2	190.5	7 1/2	190.5	9 5/8	244	9 5/8	244	10 1/2	266.7
	b	7/8	22.2	1	25.4	1 1/8	28.6	1 1/8	28.6	1 5/8	41.3	1 5/8	41.3	2 1/4	57.2
	D2	4 1/8	104.8	4 1/8	104.8	4 1/8	104.8	4 1/8	104.8	4 1/8	105	4 1/8	105	4 1/8	105
	D1	5 1/2	139.7	5 7/8	149.2	5 7/8	149.2	5 7/8	149.2	7 1/2	190.5	7 1/2	190.5	7 3/4	197
	n	4	4	8	8	8	8	8	8	8	8	8	8	8	8
	d	3/4	19	7/8	22.2	7/8	22.2	7/8	22.2	1 1/8	28.6	1 1/8	28.6	1 1/4	31.8

Grade C276 Hastelloy Flange Dimensional Tolerance

Outside Diameter	When O.D. is 24″ or less	±1.6mm﹡
Inside Diameter	10″ and smaller	±0.8mm
	12″ thru 18″	±1.6mm
	20″ and larger	+3.2mm, -1.6mm
Outside Diameter of hub	5″ and smaller	+2.4mm, -0.8mm﹡
Outside Diameter of hub	6″ and larger	+4.0mm, -0.8mm
Diameter of contact face	1/16″ rasied face tongue and groove male, female	±0.8mm
Diameter of contact face	1/4″ rasied face tongue and groove male, female	±0.4mm
Diameter of hub at base	when hub base is 24″ or smaller	±1.6mm﹡
Diameter of hub at point of welding	5″ and smaller	+2.4mm, -0.8mm
Diameter of hub at point of welding	6″ and larger	+4.0mm, -0.8mm
Drilling	Bolt circle	±1.6mm
	Bolt hole spacing	±0.8mm
	Eccentricity of bolt circle with respect to facing	2 1/2″ and smaller: 0.8mm, max﹡
	Eccentricity of bolt circle with respect to bore	3″ and larger: 1.6mm, max﹡
Thickness	18″ and smaller	+3.2mm, -0mm
Thickness	20″ and larger	+4.8mm, -0mm
Length of thru hub	10″ and smaller	±1.6mm
Length of thru hub	12″ and larger	±3.2mm

Hastelloy C276 Flange Price List

Hastelloy C276 Flanges Price List	Alloy C276 Forged Flange Price in India	UNS N10276 SORF Flange Prices
Hastelloy C276 Flange Prices	US $1.8-159 / Piece	UAE Dirham 0.087 – 7.73
Alloy C276 Pipe Flange Price Per kg	US $1500 / Ton	UAE Dirham 72.90
Alloy C276 Blind Flange Price	US $1-500 / Piece	UAE Dirham 0.049 – 24.30
Price List of ASTM B564 Orifice Flange	US $999-1499 / Piece	UAE Dirham 48.55 – 72.85

Best quality Hastelloy C276 Flanges, EN NiMo16Cr15W Plate Flange Flat Face, Hastelloy C276 Flanges Price, ASTM B564 C276 Flanges Facing Type & Finish, Hastelloy Grade C276 Square Flange, MSS SP-44 Hastelloy C276 Flange, Alloy Grade C276 Nipoflange, UNS N10276 Spectacle Blind Flange, Hastelloy C276 Class 150 Flanges Raised Face, View Specification Of ASME B16.5 C276 Hastelloy Orifice Flange, Alloy C276 Orifice Flanges, WERKSTOFF NR. 2.4819 Groove Flange, Hastelloy C276 Expander Flanges at Best Price.
