AS 2129 / 4087 Flanges

AS 2129 Table D Threaded Flanges, AS 4087 Socket Weld Flanges, AS 4087 slip on Flanges Supplier, AS 2129 Plate Flange, AS 4087 weld neck Flange, AS 2129 Spectacle blind Flanges Manufacturer in India.

AS 2129 and AS 4087 are both Australian Standards that define the specifications for flanges used in various industrial applications.

AS 2129 Flanges: AS 2129 specifies the requirements for circular flanges made from materials such as carbon steel, stainless steel, and alloy steel. The standard defines the dimensions, pressure ratings, and facing types for flanges that are intended for use in pipelines, pressure vessels, and other equipment. AS 2129 flanges are typically used in low-pressure applications.

AS 4087 Flanges: AS 4087 specifies the requirements for flanges made from materials such as ductile iron and grey iron. The standard defines the dimensions, pressure ratings, and facing types for flanges that are intended for use in water supply and sewerage applications. AS 4087 flanges are typically used in low- to medium-pressure applications.

In summary, AS 2129 and AS 4087 are both Australian Standards that define the specifications for flanges used in different industrial applications. AS 2129 flanges are typically used in low-pressure applications, while AS 4087 flanges are used in low- to medium-pressure applications in water supply and sewerage systems.

AS 2129 Flanges, AS 4087 Flanges Manufacturers and Suppliers

Specifications Dimensions & Weight Chart Applications

Ready Stock of AS 4087 Socket Weld Flange, AS 2129 Table E Blind Flanges, Check Sizes And Dimensions Of AS 4087 Forged Flanges, Suppliers of AS 4087 Welding Neck Flange, AS 2129 Ring Type Joint Orifice Flange.

AS 4087 Flange Specifications

Size Range

1/2" (15 NB) to 48" (1200NB) DN10~DN5000

Class / Pressure Rating

150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Standards / Dimensions

ANSI/ASME B16.5, B16.36, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605

Connection Type

Ring Joint Flange (RTJ), Flat Face Flange (FF), Raised Face Flange (RF), Male and Female Flange (M & F), Lap Joint Flange, Large and Small Tongue-and-Groove Flange (T & G)

AS 2129 Flanges Dimensions

AS 2129 FLANGE DIMENSIONS – TABLE D

TABLE D				LENGTH THROUGH HUB		DRILLING DATA
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANGE (Refer Note.1)	BOSSED SOW	WELD NECK	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES
MM	INCH	OD	T	L	L1	PCD	H	#
15	1/2	95	5	15	27	67	14	4
20	3/4	100	5	16	27	73	14	4
25	1	115	5	16	27	83	14	4
32	1 1/4	120	6	17	31	87	14	4
40	1 1/2	135	6	19	35	98	14	4
50	2	150	8	21	37	114	18	4
65	2 1/2	165	8	24	40	127	18	4
80	3	185	10	26	45	146	18	4
90	3 1/2	205	10	27	45	165	18	4
100	4	215	10	29	51	178	18	4
125	5	255	13	32	57	210	18	8
150	6	280	13	32	61	235	18	8
200	8	335	13	35	64	292	18	8
250	10	405	16	43	80	356	22	8
300	12	455	19	48	89	406	22	12
350	14	525	22		95	470	26	12
400	16	580	22			521	26	12
450	18	640	25			584	26	12
500	20	705	29			641	26	16
550	22	760	29			699	30	16
600	24	825	32			756	30	16
700	28	910	35			845	30	20
750	30	995	41			927	33	20
800	32	1060	41			984	36	20
850	34	1090	44			1016	36	20
900	36	1175	48			1092	36	24
1000	40	1255	51			1175	36	24
1050	42	1335	54			1251	36	28
1200	48	1490	60			1410	36	32
NOTES: (1) Plate Flanges less than 12mm thickness may suffer unacceptable distortion after welding. (2) Bore sizes to suit ASME B 36.10 pipe unless otherwise specified. (3) Flanges are generally supplied flat faced. (4) All dimensions are in millimetres (mm)

AS 2129 FLANGE DIMENSIONS – TABLE E

TABLE E				LENGTH THROUGH HUB		DRILLING DATA
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANGE (Refer Note.1)	BOSSED SOW	WELD NECK	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES
MM	INCH	OD	T	L	L1	PCD	H	#
15	1/2	95	6	16	28	67	14	4
20	3/4	100	6	17	28	73	14	4
25	1	115	7	18	29	83	14	4
32	1 1/4	120	8	19	33	87	14	4
40	1 1/2	135	9	22	38	98	14	4
50	2	150	10	23	39	114	18	4
65	2 1/2	165	10	26	42	127	18	4
80	3	185	11	27	46	146	18	4
90	3 1/2	205	12	29	47	165	18	8
100	4	215	13	32	54	178	18	8
125	5	255	14	33	58	210	18	8
150	6	280	17	36	65	235	22	8
200	8	335	19	41	70	292	22	8
250	10	405	22	49	86	356	22	12
300	12	455	25	54	95	406	26	12
350	14	525	29		102	470	26	12
400	16	580	32			521	26	12
450	18	640	35			584	26	16
500	20	705	38			641	26	16
550	22	760	44			699	30	16
600	24	825	48			756	33	16
700	28	910	51			845	33	20
750	30	995	54			927	36	20
800	32	1060	54			984	36	20
850	34	1090	57			1016	36	20
900	36	1175	64			1092	36	24
1000	40	1255	67			1175	39	24
1050	42	1335	70			1251	39	28
1200	48	1490	79			1410	39	32
NOTES: (1) Plate Flanges less than 12mm thickness may suffer unacceptable distortion after welding. (2) Bore sizes to suit ASME B 36.10 pipe unless otherwise specified. (3) Flanges are generally supplied flat faced. (4) All dimensions are in millimetres (mm)

AS 2129 FLANGE DIMENSIONS – TABLE F

TABLE F				LENGTH THROUGH HUB		DRILLING DATA
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANGE (Refer Note.1)	BOSSED SOW	WELD NECK	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES
MM	INCH	OD	T	L	L1	PCD	H	#
15	1/2	95	10	20	32	67	14	4
20	3/4	100	10	21	32	73	14	4
25	1	120	10	21	39	87	18	4
32	1 1/4	135	13	24	48	98	18	4
40	1 1/2	140	13	26	48	105	18	4
50	2	165	16	29	51	127	18	4
65	2 1/2	185	16	32	54	146	18	8
80	3	205	16	32	60	165	18	8
90	3 1/2	215	19	36	63	178	18	8
100	4	230	19	38	70	191	18	8
125	5	280	22	41	79	235	22	8
150	6	305	22	41	79	260	22	12
200	8	370	25	47	92	324	22	12
250	10	430	29	56	102	381	26	12
300	12	490	32	61	111	438	26	16
350	14	550	35			495	30	16
400	16	610	41			552	30	20
450	18	675	44			610	33	20
500	20	735	51			673	33	24
550	22	785	54			724	33	24
600	24	850	57			781	36	24
700	28	935	60			857	36	24
750	30	1015	67			940	36	28
800	32	1060	68			984	36	28
850	34	1090	70			1016	36	32
900	36	1185	76			1105	39	32
1000	40	1275	83			1194	39	36
1050	42	1355	86			1270	39	36
1200	48	1530	95			1441	42	40
NOTES: (1) Plate Flanges less than 12mm thickness may suffer unacceptable distortion after welding. (2) Bore sizes to suit ASME B 36.10 pipe unless otherwise specified. (3) Flanges are generally supplied flat faced. (4) All dimensions are in millimetres (mm)

Find the largest ready stock of AS 2129 Table F Flanges, Check Availability of AS 2129 Threaded Flanges, AS 4087 Slip On Flanges Dealer, AS 2129 Reducing Flanges Stockist, AS 4087 RF Flanges Supplier, AS 4087 Flange Price List, AS 2129 Forged Flanges in Mumbai, India.

AS 2129 FLANGE DIMENSIONS – TABLE H

TABLE H				LENGTH THROUGH HUB		DRILLING DATA
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANGE	BOSSED SOW	WELD NECK	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES
MM	INCH	OD	T	L	L1	PCD	H	#
15	1/2	115	13	23	42	83	18	4
20	3/4	115	13	24	42	83	18	4
25	1	120	14	25	43	87	18	4
32	1 1/4	135	17	28	52	98	18	4
40	1 1/2	140	17	30	52	105	18	4
50	2	165	19	32	54	127	18	4
65	2 1/2	185	19	35	57	146	18	8
80	3	205	22	38	66	165	18	8
90	3 1/2	215	22	39	66	178	18	8
100	4	230	25	44	76	191	18	8
125	5	280	29	48	86	235	22	8
150	6	305	29	48	86	260	22	12
200	8	370	32	54	99	324	22	12
250	10	430	35	62	108	381	26	12
300	12	490	41	70	120	438	26	16
350	14	550	48			495	30	16
400	16	610	54			552	30	20
450	18	675	60			610	33	20
500	20	735	67			673	33	24
550	22	785	70			724	33	24
600	24	850	76			781	36	24
NOTES: (1) Plate Flanges less than 12mm thickness may suffer unacceptable distortion after welding. (2) Bore sizes to suit ASME B 36.10 pipe unless otherwise specified. (3) Flanges are generally supplied flat faced. (4) All dimensions are in millimetres (mm)

Best quality AS 4087 Flanges, AS 4087 Groove Flange, AS 4087 Nipoflange, AS 4087 RTJ Flange, AS 4087 Weldoflange, AS 2129 Square Flange, AS 2129 Flanges Price, View Specification Of AS 2129 Orifice Flange, AS 2129 Table H Flanges Facing Type & Finish, AS 2129 langes Raised Face, AS 2129 Expander Flanges at Best Price.

AS 2129 Flanges Applications
